Model: TP-W18 TP-W30 TP-W40
This series are designed for ultrasonic welding different size copper wire. Mainly suitable for splicing copper wire, and aluminum wire.
Support a variety of welding modes, and has data storage, air pressure detection, and other functions.
This series are designed for ultrasonic welding different size copper wire. Mainly suitable for splicing copper wire, and aluminum wire.
Support a variety of welding modes, and has data storage, air pressure detection, and other functions.
1. Fully numerically controlled, the machine has preset parameters for different sizes of wire, only needs to adjust to the required welding square parameters, and call the preset parameters. Also support parameter tuning.
2. It has the preventing empty welding function, which can effectively prevent damage to the welding head.
3. Ultrasonic scanning detection, the welding power can be monitored in real-time during welding, which can effectively ensure the yield during welding.
4. Adopt a pure cylinder motion system, easy to use and easy to operate.
5. Compact structure and lightweight design
| Model | TP-W18 | TP-W30 | TP-W40 |
| Welding capacity | Wire size range: 0.5-18mm2 | Wire size range: 1-30mm2 | Wire size range:3-40mm2 |
| Frequency | 20Khz | 20Khz | 20Khz |
| Power Supply | 220VAC,50Hz | 380VAC,50Hz | 380VAC,50Hz |
| Power | 3000W | 4000W | 6500W |
| Weight | 25kgs + 15kgs | 30kgs + 15kgs | 35kg + 15kgs |
The ultrasonic wire harness welding machine is widely used in the fields of automobiles, electronic appliances, motors, communication equipment, mechanical equipment, instruments and so on.
