Model: PF-S68 PF-S88
This fully automatic wire feeder eliminates the trouble of manual wire feeding. It is suitable for various wires and cables.
PF-S68 PF-S69 Max 200kgs electric wire pre feeding machine wire feeder
Description
Wire spool pre feeding machine
This fully automatic wire feeder eliminates the trouble of manual wire feeding. It is suitable for various wires and cables.
Main body material: welded with high quality national standard rectangular tube, the structure is firm and the appearance is beautiful
The maximum feeding speed is 4 m/s, and the maximum wire diameter is 18mm.
Wire spool unwinding machine video
Technical Data
| Model | PF-S68 | PF-S69 |
| Available Wire Diameter | ≤ Φ30mm | ≤ Φ30mm |
| Available Spool Width (height) | max 680mm | max 680mm |
| Available Spool Out Diameter | 200-720mm | 600-1200mm |
| Available Spool Inner Diameter | No limit | No limit |
| Max Load Weight | 100kg | 220kg |
| Feeding Speed | 0-60 m/min | 0-60 m/min |
| Power Supply | 380V / 220V | |
| Available Wire | Wire, cable etc. | |
| Drive Type | Inverter & motor & reducer | |
| Dimensions | 104*62*140cm | 205*156*185cm |
| Weight | 135kg | 550kg |
Application
This fully automatic wire feeder eliminates the trouble of manual wire feeding.
Download
If you wish to have the datasheet of this or other products, you can let us know here: CONTACT
Or email to [email protected], we will send you the machine introduction.
Get Details & Price Now
If you hope to inquiry just this product, please send a message here. If you hope to inquiry several products, please Add To Quote, quote all products on the Request Quote page.
WIREPRO will send quotes back to you ASAP : ）
