Model: HW-S05
The HW-S05 is designed for tape point wrapping. It can work with different types of material tape include tape with back paper.
HW-S05 professional tube wire harness spot taping machine
Description
The HW-S05 is designed for tape point wrapping. It can work with different types of material tape including tape with back paper. Mainly used for automobile, motorcycle, and aviation industry, point taping for marking, fixing, or insulation.
1. Tape length accurately, tape edge wrapping neatly
2. Fully automatically cut the tape when finished wrapping
3. Touch screen, PLC control system, easy to operate, compact design, small size
4. The tape length of one set machine can be adjusted in the longest and shortest range of 5mm
5. Machine work is stable and high efficiency, reducing the operation difficulty of manual
HW-S05 Spot taping machine video:
| Model | HW-S05 |
| Features | Professional spot winding, neat wrapping edges, automatic cut tape |
| Available Tape Length | Standard machine: 50mm (adjustable range about ±5mm): Custom Available: 15, 30, 40, 70-90 mm(based on materials) |
| Tape Width | 20-45mm ( can custom) |
| Taping diameter | Customized, requires different parts; Generally, 1-16mm and not more than 20mm. |
| Power | 220/110V, 50/60Hz |
| Dimensions | 50*36*36cm |
| Weight | 48kg |
Application
HW-HD35 supports wire harness continuous & spot taping.
