Model: CB-T15
CB-T15 Nylon braid race hose automatic cutting and tape wrapping machine
Descrizione
Video:
Technical Data
| Model | CB-T15 |
| Function | Automatic cutting tape and wrap around on hose, automatic cutting the hose |
| Hose Diameter * | Φ8-15mm |
| Hose Cutting Length | 1-99999mm |
| Cutting Length Tolerances | ≤ ±1 mm (L<1000) |
| Cutting Speed | 600-700pcs/h (hose length 800mm) |
| Tape Type | Non-elastic adhesive tape |
| Tape Width * | 10 -20 mm |
| Taping Round | Can be set |
| Taping Speed | 4 second/time |
| Wire Feed Method | Belt feeding |
| Power Supply | 220V / 110V(custom) |
| Power | 1800W |
| Weight | 380kg |
| Dimensions | 170*60*150cm |
| Note: * mark parameters custom available. If you are in doubt, we are happy to process your sample. | |
