Model: CW-A15
Automatic cutting machine for wire, cable, tube. Cable max 150 sqmm, support strip one end.
CW-A15 Automatic tube wire cable cutting one end strip machine
Descripción
Full-automatic cutting cable machine, max 150 sqmm, support strip one end. Can process cable like the automotive industry power cable, electric control cabinet, battery box cable, new energy vehicle wiring harness, high power supply shielding cable, charging pile harness.
Features:
1. Processing cable below 150 sqmm, improving working efficiency
2. Compared to the SU-150, this model price is very good, save equipment cost.
3. Belt feeding cable, no embossing, no scratches
4. Automatically identify the machining center, increase the production rate
5. Uses specific axial positioning and advanced tool holders, improving accuracy and production rate.
6. Digitally Display Screened cutting wire diameter, high-quality pneumatic components, more energy-saving, and work stably.
7. Optional auxiliary equipment: automatic wire feeder, wire stacker or coiler etc.
Can cut tube and other materials too.
CW-A15 cable cutting machine video:
Datos técnicos
| Modelo | CW-A15 |
| Function | Cutting & one end stripping |
| Conductor Cross-Section | 1-150mm² |
| Cutting Length | 1-99999mm |
| Cutting Length Tolerances | ≤(0.002*L) mm |
| Stripping Length * | Head 1-800mm; Tail No |
| Conduit Diameter * | Φ33mm |
| Production Rate | 1000-1800pcs/h |
| Display Screen | 7 inch touch screen |
| Wire Feed Method | Belt feeding |
| Drive Method | 16 wheels drive |
| Fuente de alimentación | 220V/110V |
| Power | 1600W |
| Peso | 90kg |
| Dimensiones | 100*80*76cm |
| Note: * mark parameters custom available. If you are in doubt, we are happy to process your sample. | |
